current location：Home>Products>Optics Mounts Series>Optics Mounts

SLM200 series self-centering lens mounts

    1. Three pivots of the coaxial lens mounts continuously open simultaneously, automatic reset by spring

    2. When the replacement of lens, center of lens will be not changed

    3. Two dimensional tilt adjustment driving by M6×25 fine thread screw

  • description
  • parameters

SLM200 series self-centering lens mounts




1. Three pivots of the coaxial lens mounts continuously open simultaneously, automatic reset by spring

2. When the replacement of lens, center of lens will be not changed

3. Two dimensional tilt adjustment driving by M6×25 fine thread screw



Model

SLM201

SLM202

Applied diameter ΦA(chǔ)

MIN

5

5

MAX

50

76

Adjusting rang of tilt

±5°

±5°

C

26

31

D

74

104

E

39

51

F

34

39

Weight（kg）

0.25

0.3
